HID over I2C (Human Interface Device over I2C)

HID over I2C Protocol Analyzer settings. For Channel UI differences by product family, see Settings.

Supported Models

TravelBus

All TB1000/TB2000/TB3000 models are supported except F series.

LA3000/LA4000

LA3000 is supported only on B/Plus series, all LA4000 models are supported.

TravelLogic

TL3000 is supported only on B series, all TL4000 models are supported.

BusFinder

BF6000 is supported only on B series, all BF7000 models are supported.

Protocol Exerciser

PX2816B is supported.

MSO2000/3000

MSO1000/MSO2000 16-channel models are supported, all MSO3000 models are supported.

TravelScope 3000

All TS3000 models are supported.

Settings

HID over I2C Settings

HID over I2C Protocol Analyzer settings (TravelLogic series)
  • Settings:
    • 7-bit addressing: Addressing mode (7-bit addressing / 8-bit addressing (Include R/W in Address) / 10-bit addressing). A wrong setting mis-decodes HID slave addresses. Default: 7-bit addressing.
