MDIO (Management Data Input/Output)

MDIO Protocol Analyzer settings. For Channel UI differences by product family, see Settings.

Supported Models

TravelBus

All TB1000/TB2000/TB3000 models are supported except F series.

LA3000/LA4000

LA3000/LA4000 is supported only on B series.

TravelLogic

TL3000/TL4000 is supported only on B series.

BusFinder

BF6000 is supported only on B series, all BF7000 models are supported.

Protocol Exerciser

PX2816B is supported.

MSO2000/3000

MSO2008E	MSO2116E	MSO2116B	MSO2216B	MSO2216B+	MSO2416B+
		●	●	●	●

MSO2216M+	MSO2116E+	MSO2116B+
●		●

All MSO3000 models are supported.

TravelScope 3000

All TS3000 models are supported.

Settings

MDIO Protocol Analyzer settings (TravelLogic series)

• Settings:
  • Bypass TA (Turnaround) error: Skip turnaround-phase error checks (useful when the PHY is loose on TA). Default: checked.
  • Preamble Bits: Preamble bit count. Default: 32.
  • Sample Rate: MDIO analysis sample rate (50 MHz / 200 MHz). Main Default button does not reset this field; new protocol defaults to 50 MHz.
