BiSS-C (BiSS-C)

BiSS-C Protocol Analyzer settings. For Channel UI differences by product family, see Settings.

Supported Models

TravelBus

TB1000 is supported only on Plus series, TB2000/TB3000 is supported only on B series.

LA3000/LA4000

LA3000 is supported only on B/Plus series, all LA4000 models are supported.

TravelLogic

TL3000 is supported only on B series, all TL4000 models are supported.

BusFinder

BF6000 is supported only on B series, all BF7000 models are supported.

Protocol Exerciser

PX2816B is supported.

MSO2000/3000

MSO1000/MSO2000 16-channel models are supported, all MSO3000 models are supported.

TravelScope 3000

All TS3000 models are supported.

Settings

BiSS-C Settings

BiSS-C Protocol Analyzer settings (TravelLogic series)
  • Settings:
    • Serial data length (bits): BiSS serial data bit length. A wrong setting can shift decoding. Default: 12.
